Feature Description

● 90A contact switching capability
● Electrical endurance capability: breaking under 2000A for 0.3ms for 300 times
● We can provide the contact gap is > 1.5mm
● Contact on and off can be controlled by manual control switch
● UL insulation system:Class F
● Outline Dimensions:FH30L-90：(39.0×15.0×30.2)mm
　　　　　　　　　　FH30LD-90：(39.0×21.4×30.2)mm
● Main application:charging pile,Smart home,Lighting control
